The Rainbow Papaya in Hawaii is a great example of how biology solved a devastating problem that nature created and chemicals could not fix. It put GMOs, the successor to mutagenesis, on the map worldwide, and today billions of meals have been served using GMO science.

Now a papaya (Carica papaya) may give sugar a boost also.  As it ripens its cell walls separate, making the tissue softer so the cell contents become more accessible and the sucrose in the fruit is more easily extracted. Sugarcane roots undergo a similar process. Their cell walls are modified during development to form gas-filled intercellular spaces in a type of tissue known as aerenchyma. Aerenchyma is very common in crops grown in flooded fields, such as rice, since it supports them or enables them to float in water while also allowing the submerged parts of the plant to breathe in oxygen and breathe out carbon gas.

In recent years, São Paulo Bioscience Institute Professor Marcos Buckeridge and collaborators have focused on studying the genes involved in sugarcane root cell separation with the aim of developing transgenic varieties of sugarcane in which the process occurs in other parts of the plant, such as the stem, where biomass and sucrose accumulate. The cell walls in these varieties would be as soft as in a papaya - hence the nickname "papaya sugarcane" - and could more easily be degraded to produce second-generation bioethanol (obtained from biomass) on a large scale.

Sugarcane root aerenchyma seen under a microscope. Credit: Débora Chaves Coelho Leite

They describe the first gene sequences involved in sugarcane root cell separation and elucidated their functions in the Journal of Experimental Botany.

"If we succeed in promoting cell wall separation in the sugarcane stem, it will be possible not only to reduce the amount of enzyme cocktails used for enzymatic hydrolysis [degradation of the carbohydrates in sugarcane trash and bagasse and their conversion into fermentable sugar] to obtain second-generation ethanol but also to increase sucrose extraction," Buckeridge, principal investigator for INCT Bioethanol, said.

The researchers sequenced two genes considered essential to the initial stages of aerenchyma development in sugarcane roots. The first was scRAV1, which encodes the RAV transcription factor that controls plant leaf aging. The second was scEPG1, which encodes endopolygalacturonase (EPG), an enzyme that degrades the pectin that keeps cells together, thereby contributing to cell separation and the softening of fruit tissue via aerenchyma formation.

Owing to the complexity of the sugarcane genome, which has several copies of each chromosome and numerous variants of each gene, the two genes were sequenced from 17 artificial bacterial chromosome clones containing genomic regions homologous to those of the R570 sugarcane variety.

The gene sequences were compared with those of the corresponding regions of Sorghum bicolor (the sorghum genome closely resembles the sugarcane genome). A similar sequence from each of the two genes was expressed in tobacco leaves for transactivation assays to see which other genes they activated.

"Tobacco is easy to transform genetically and serves as a model to demonstrate how mechanisms like this actually work," Buckeridge said.

Analysis of the genomic regions and the transactivation assays showed that scRAV1 controls early pectin degradation during sugarcane root aerenchyma formation and that the protein produced by scRAV1 binds to the scEPG1 promoter, blocking transcription of this gene.

"Our findings pave the way for using biotechnology for the genetic manipulation of sugarcane to boost the production of second-generation ethanol," Buckeridge said.
First step

The researchers developed a sugarcane variety with enhanced expression of scRAV1. They also discovered a microRNA (a molecule that regulates gene expression) capable of specifically inhibiting scRAV1 and stimulating the expression of scEPG1throughout the plant.

"In this genetically transformed variety, we're starting to see what seems to be a softening of the sugarcane cell wall, similar to the effect we want. The stems of some of the plants, for example, are unable to stay erect. This could be the first step toward the development of papaya sugarcane," Buckeridge said.
