Up-and-down ripples, swings that rise and recede like the teeth on a saw blade, are found in everything from stock prices on Wall Street to ocean waves; and they occur periodically in the temperature and density of the plasma that fuels fusion reactions in doughnut-shaped facilities called tokamaks. If the swings combine with other instabilities in the plasma they can halt the reactions. Why some plasmas are free of sawtooth gyrations has long puzzled physicists.

Fusion, the power that drives the sun and stars, is the fusing of light elements in the form of plasma -- the hot, charged state of matter composed of free electrons and atomic nuclei -- that generates massive amounts of energy. Scientists are seeking to replicate fusion on Earth for a virtually inexhaustible supply of power to generate electricity, replacing nuclear fission the way the automobile replaced the horse.

And now researchers at the U.S. Department of Energy's (DOE) Princeton Plasma Physics Laboratory (PPPL) have tackled "magnetic flux pumping", the mechanism which limits the current in the core of the plasma that completes the magnetic field that confines the hot, charged gas that produces the reactions.

This development, found in some fusion plasmas, keeps the current from becoming strong enough to trigger the sawtooth instability. Spearheading the research that uncovered the process was physicist Dr. Isabel Krebs, lead author of a Physics of Plasmas paper describing the mechanism. Krebs used the PPPL-developed M3D-C1 code to simulate the process on the high-performance computer cluster at PPPL.


Dr. Isabel Krebs. Credit: Elle Starkman/PPPL Office of Communications

Hybrid scenarios

In the PPPL simulations, magnetic flux pumping develops in "hybrid scenarios" that exist between standard regimes -- which include high-confinement (H-mode) and low-confinement (L-mode) plasmas -- and advanced scenarios in which the plasma operates in a steady state. In hybrid scenarios, the current remains flat in the core of the plasma while the pressure of the plasma stays sufficiently high.

This combination creates what is called "a quasi-interchange mode" that acts like a mixer that stirs up the plasma while deforming the magnetic field. The mixer produces a powerful effect that maintains the flatness of the current and prevents the sawtooth instability from forming. A similar process maintains the magnetic field that protects the Earth from cosmic rays, with the molten liquid in the iron core of the planet serving as mixer.

The mechanism also regulates itself, as the simulations show. If the flux pumping grows too strong, the current in the core of the plasma stays "just below the threshold for the sawtooth instability," according to Krebs. By remaining below the threshold, the current keeps the plasma temperature and density from zigzagging up and down.

The simulations could lead to measures to avoid the troublesome swings. "This mechanism may be of considerable interest for future large-scale fusion experiments such as ITER," Krebs said. For ITER, the major international fusion experiment under construction in France, creation of a hybrid scenario could produce flux pumping and deter sawtooth instabilities

One way to develop the hybrid scenario will be for operators of ITER to experiment with the timing of the neutral beam power that will heat the ITER plasma to fusion temperatures. Such experiments could lead to the combination of plasma current and pressure that produces sawtooth-free operation.
